Screw Feeder, Stainless Steel Coil Processing, Guangdong Ruihui Servo Feeder Price, automatic bolt welding machine
www.ruihui.net
The screw feeder is used for the feeding of parts of various sizes of screws or similar screws with M1.0-5.0 and length less than 15 and the machine takes the materials.
Screw Feeder Features
1. This machine can be used with a variety of screws, such as (1.0, 1.2, 1.4, 1.7, 2.0, 2.3, 2.6, 3.0, 3.5, 4.0, 5.0) common screws;
2. can also be applied to special screws, especially suitable for 1:1 short screws, with gasket screws;
3. adjust the track, replace the distribution tray and the distribution board to adapt to different screws;
4. Different parameters can be set through the digital display panel, the adjustment is convenient, and the parameters are intuitive;
5. the turntable material, the position accuracy of the material is ± 0.02, with the card material reversal function;
6, with automatic counting function, through the digital display panel, the number of counts at a glance;
7. It is equipped with automatic machine, and there is signal to the automatic machine. The automatic machine can directly take the material from the turntable.
8. small size, does not take up space, does not card screws, high production efficiency.
Specification:
| Model | MAC2-400 | MAC2-500 | MAC2-600 | MAC2-800 |
| Stock Width(mm) | 50-400 | 50-500 | 50-600 | 50-800 |
| Stock Thickness(mm) | 0.3~3.2 | 0.3-3.2 | 0.3-3.2 | -3.2 |
| Max.Coil Weight(kg) | 3000 | 3000 | 3000 | 5000 | 5000 | 7000 |
| Max.Coil O.D.(mm) | 1200 | 1200 | 1200 | |
| Coil I.D.(mm) | 8 | 8 | 508 | 508 |
| Feed Length(mm) | ~500* | ~500* | ~500* | ~500* |
| Max. Line Speed(m/min) | 16-24 | 16-24 | 16-24 | 16-24 |
| Work Roll Number(pieces) | upper 6
lower 5 | upper 6
lower 5 | upper 6
lower 5 | upper 6
lower 5 |
| Feed Roll Number(set) | 1 | 1 | 1 | 1 |
| Main Motor(kw) | AC2.9 | AC2.9 | AC4.4 | AC4.4 |
| Mandrel Expansion | hydraulic | hydraulic | hydraulic | hydraulic |
| Reel Motor(kw) | 1.5 | 1.5 | 1.5 | 2.2 | 2.2 | 3.7 |
| Power(V) | 3 Phase 220V/380V/50HZ |
| Operating Air(Mpa) | 0.49 | 0.49 | 0.49 | 0.49 |
Straigtening performance:
| tock Thicknees (mm) | Stock Width (mm) |
| 0.3 | 400 | 500 | 600 | 800 |
| 0.4 |
| 0.6 |
| 0.8 |
| 1.0 |
| 1.2 |
| 1.4 |
| 1.6 | 470 | 470 |
| 1.8 | 400 | 400 |
| 2.0 | 360 | 360 |
| 2.3 | 300 | 300 | 300 | 300 |
| 2.5 | 230 | 230 | 230 | 230 |
| 2.8 | 150 | 150 | 150 | 150 |
| 3.2 | 110 | 110 | 110 | 110 |
*1:(Pneumatic):Option in case of pneumatic mandrel expansion is provi
1. Pre-Sales Service:We have professional designers to meet the different requirement of our customers.
2. After-Sales service:We have an efficient team to meet 24*7 all day service.
3. Full-Service:Actively cooperate with customers to deal with problems in equipment using.
4. Engineers can provide service machinery overseas.
